Lajanje na zvezde ceo film online sa prevodom. Hi Anthony, Thank you for submitting a question to Manage My Life. The inverter on this washer is the motor control board. The main control is the 'brain' for all other functions. The inverter receives commands from the control board and controls motor operation. The inverter is enclosed in a protective housing and is located on the chassis, under the left side of the outer tub. It is inserted in 2 guides at the rear and held in place by a single Phillips-head screw at the front. For the inverter to operate the motor correctly requires a supply voltage of 120 VAC, DC input from the control board, and the three motor windings intact.

Specific failures associated with the inverter can initiate error codes E43, E4A, E4B, E4C, E4E, E4F, and E53. There is not an E56 error code that I am aware of. The E70 = Stuck key Continuous key read for 60 seconds.

In the service mode: t10 = Tumble test. Display shows tt. Wash basket spins in one direction for 5seconds, pauses, and then spins in the opposite direction for 5 seconds. Repeats until exit initiated. (Note: Beginning direction is random.) t11 = Spin speed-low spin/high spin test. Display shows rpm. Pump runs, displays 0, then wash basket ramps to 400 rpm.

Press Start/Pause a second time to ramp to 1000 rpm. (May display 999 or 0 for 1000 rpm.) Then motor is unpowered, displays 0, pump runs, and returns to t11. T14 = Spin speed ramp up test. Display shows rpm. Pump runs, displays0, then wash basket ramps to 100 rpm, pauses, ramps to 350 rpm, pauses, then ramps to and holds at 1000 rpm.

The Mouse and the Cursor. As the cursor moves over different parts of windows or into different windows, the system (or an application) changes the appearance of the cursor. For example, when the cursor crosses over a hyperlink, the system changes the cursor from an arrow to a hand. 50 Best Mouse Cursors Schemes For Windows. From Windows XP to Windows Vista to Windows 7, 8, 8.1 and now, Windows 10, lots of things changed in layout or functionalities inside Windows operating system but the most frequently used thing is as it is – The mouse cursor. Unlike other changes and upgrades, the mouse cursor has seen little. ICO (file format) The ICO file format is an image file format for computer icons in Microsoft Windows. ICO files contain one or more small images at multiple sizes and color depths, such that they may be scaled appropriately. In Windows, all executables that display an icon to the user, on the desktop, in the Start Menu. Posts: 31,465. How to Change Mouse Pointers in Windows 10. A mouse pointer or cursor is a graphical image on the PC monitor or other display device. The pointer echoes movements of the pointing device, commonly a mouse, touchpad, or stylus pen, signals the point where actions of the user take place. Cursor format windows. The.ani file format is used for reading and storing Windows Animated Cursors (animated mouse pointer). A.ani file is a structured format (Microsoft RIFF) that contains information about the animation (author & title, steps, length & order of each step.) followed by several frames stored in the icon format.

(May display 999 or 0 for 1000 rpm.) The rest of the test does not involve the motor or the inverter (motor control board). To check the inverter: Always unplug or de-energize electrical equipment before removing covers or attempting service. Be careful and wear appropriate hand protection when working around sharp metal parts.

Working with live electrical current can be very hazardous and possibly deadly. Do not attempt these measurements without the proper tools and safeguards. If you are not already sure you can perform these checks safely and competently, refer this work to a qualified professional.

• Remove the service panel. • Press the 4 tabs inward and remove the junction box cover. • Enter test mode t10, t11, or t14.

• Check for 120 VAC between the blue and red wires at the AC input harness. Note: The 120 VAC inverter supply voltage is present only when the motor is supposed to be operating. • Unplug washer, then check motor resistance. If 120 VAC is present at the AC input harness and motor resistance is correct, replace the inverter. Note: If the inverter overheats, the washer will stop for 5 minutes. To check the motor: • Remove the service panel.

• Disconnect the motor wire harness. • On the motor plug, check for an approximate resistance value of 6 ohms between any two of the three wires: Blue to white - 6 OHMS Blue to red - 6 OHMS White to red - 6 OHMS The sensor has a resistance value of approximately 118 OHMS between the two orange wires. If you do not feel confident repairing this problem yourself, then you can have it repaired at your home by a Sears technician. Here is a link for the website:. Here is a link that you may use to view the parts list diagram or to purchase any parts needed;. I hope this is helpful. Check the things I have covered here, and if I may be of further assistance, include more details in a reply to this post.

Anthony, These washers can be difficult to diagnose and not my favorite to work on! From what you are describing it is possible the door lock or the main control could be causing this. Typically you will get a door lock error though. I recommend you Perform T02 test to check for any stored Error Codes.

To run T02, remove power to washer for 30 seconds. Reapply power, press Signal button, press Delay Start button, press Signal button again, and press Delay Start button again.

When T01 comes up on the display (possibly up to 3-minute delay before T01 is displayed), rotate the Cycle Select knob until T02 is displayed, then press Start button. The first Error Code, if any, will be displayed at this time. If no Error Codes, display will show E00. Rotate the Cycle Select knob clockwise up to 10 clicks to view any additional Error Codes. I am including the wiring diagram for this washer in the image below. Check the door lock and door switch carefully.
