I've got 3 logical drives in dynamic smart array controller, and on installation screen I see only physical drives. Ubuntu; Community. How To Install Ubuntu 14.04 on HP Dynamic Smart Array b120i logical drive. How to use HP's RAID driver for Smart Array B120i, e.g. ProLiant Microserver G8. I have a new HP DL120_G7 that comes with a HP Smart Array B110i SATA RAID Controller. HP does have controller drivers for Red Hat / SUSE,. That it should be possible to get the controller working under Linux.

Testing details This system was tested with 14.04 LTS, running the 3.13.0-35-generic kernel. Certification notes HP Dynamic Smart Array System is certified with Dynamic Smart Array disabled. To disable Dynamic Smart Array: * Press F9 to boot into RBSU * Navigate to System Options -> HP Dynamic Smart Array B320i and select disable * Go to System options -> SATA Controller options and select Legacy SATA or AHCI * Reboot the machine and now you will be able to install the OS. HPDSA Driver Installation (MAAS) This system requires the HPDSA driver for 'smart array mode'. In order to use systems with Dynamic Smart Array controllers in 'smart array mode' with MAAS, you will need to modify drivers.yaml to include the hpdsa driver. Instructions for this can be found here: HP ILO and MAAS ILO firmware version 2.30 will not work with MAAS. To use this system in a MAAS environment you will need to update to the latest ILO firmware (greater than version 2.30).

If you are using ILO 2.20 or older, you are not affected by this issue. Please refer to HP for more information on updating ILO firmware. BIOS HP: U20 (UEFI) Hardware summary This system was tested with these key components: Processor Video Ethernet Hardware details BIOS Chassis Disk Efi Mouse Network Processor Raid System Usb Video Other.

[quote] TrevorH wrote: The installation instructions on the page that I linked to should be followed exactly as-is. They don't require any changes.[/quote] When I write 'chroot /mnt/sysimage' the system give me the message ' chroot: failed to run command '/bin/sh': No such file or directory The directory /mnt/sysimage/tmp/DD-0 has the file 'unzipped' with '# dd if=hpahcisr-1.2.4-10b.rhel5.i686.dd of=/dev/fd0 bs=1440k' If I go into the sub DD-0 and I launch 'sh./fix_driver_order' the message is sh:./fix_driver_order: No such file or directory Where I made a mistake?

Right, well at a guess then you had managed to install a set of packages that did not include /bin/sh though I didn't even know that was possible. You could try running [code] chroot /mnt/sysimage /bin/bash [/code] and see if that works. You need to get the chroot to work so that what follows affects your newly installed system and not the system that is booted from the CD - chroot changes the root directory to whatever you specify and makes it appears as though you are now in / instead of /mnt/sysimage/.
